Fiberglass Mesh

Fiberglass Mesh

Glue content: 13-20%
Weave type: Twill woven,Plain Woven
Customise acceptable
Free sample
Product description: Fiberglass Mesh is woven by fiberglass yarn as its basis mesh, and then coated by alkaline resistant latex. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in cons
INQUIRY

Fiberglass Mesh is woven by fiberglass yarn as its basis mesh, and then coated by alkaline resistant latex. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in construction,it is
mainly used to reinforce cement, stone, wall materials, roofing, and gypsum and so on.We can
produce any size mesh according to your requirements ,like different mesh size and weight per square meter.
We can supply special mesh as following:
(1) High strength mesh
(2) Fire proof mesh
(3) Strong and flexible mesh
(4) Fiberglass self adhesive tape
We can supply specifications from 30g/m2 to 500g/m2 for mesh.

Main size: 5mm x 5mm or 4mm x 4mm, 75 g/m2, 90 g/m2, 125 g/m2,145 g/m2, 160 g/m2.

Mesh Size (mm)		Finished weight (g/m2)	Tensile StrengthX20cm		Content of resin %(≥)
Warp	Weft	Finished weight (g/m2)	Warp	Weft	Content of resin %(≥)
10	10	60	500	650	17
4	5	75	600	650	18
5	5	80	700	850	18
5	5	90	700	1050	18
4	4	100	750	1000	18
10	10	100	1000	1250	20
4	5	120	1000	1300	18
5	5	125	1200	1300	18
10	10	125	1250	1450	20
5	5	135	1300	1400	18
4	4	135	1000	1300	18
4	5	140	1300	1350	18
10	10	145	1250	1700	20
5	5	145	1400	1500	18
4	5	150	1300	1300	18
5	5	160	1450	1600	18
4	4	160	1550	1650	18
4	5	165	1300	1300	18
4	4	170	1450	1700	18
4	5	200	1500	2200	18
